Gigabyte B760M GAMING X DDR4 GEN5 Intel 1700 Socket Motherboard, Micro-ATX, 4x DDR4 Slots, 2x M.2 Sockets, Fitted I/O Shield, 2.5GbE LAN, 1x DisplayPort / 1x HDMI Port
$188.00
B760M GAMING X DDR4 GEN5 Motherboard
The B760M GAMING X DDR4 GEN5 motherboard is designed for PCIe Gen5 performance, advanced thermal solutions, and versatile connectivity, supporting the latest Intel® desktop processors and high-speed DDR4 memory.
Key Features
- PCIe Gen5 Performance
-
PCIe Gen5 support with perfect sync for winning performance
-
Processor Support
-
Supports Intel® Core™ 14th, 13th, and 12th Generation processors
-
Efficient Thermal Design
- VRM Thermal Armor Advanced
-
M.2 Thermal Guard
-
EZ-Latch
-
PCIe 5.0 x16 slot with quick release design
-
PCIe UD Slot
-
SMD PCIe 5.0 armor for enhanced graphics card support
-
Unparalleled Power Performance
-
Hybrid 8+1+1 phases VRM solution
-
Dual Channel DDR4 Memory
-
4 DIMM slots with XMP memory module support
-
Fast Networking
-
2.5GbE LAN
-
Extended Connectivity
- Front USB-C® 10Gb/s
-
DisplayPort and HDMI
-
Next Generation Storage
-
2 x PCIe 4.0 x4 M.2 connectors
-
Smart Fan 6
- Multiple temperature sensors
-
Hybrid fan headers with FAN STOP
-
Q-Flash Plus
- Update BIOS without installing CPU, memory, or graphics card
Specifications
CPU
| Item | Details |
|---|---|
| Socket | LGA1700 |
| Support | 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® Processors |
| Note | L3 cache varies with CPU (see GIGABYTE website for latest CPU support list) |
Chipset
| Item | Details |
|---|---|
| Chipset | Intel® B760 Express Chipset |
Memory
| Item | Details |
|---|---|
| Memory Type | DDR4 |
| Supported Speeds (MT/s) | 5333(O.C.) / 5133(O.C.) / 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2666 / 2400 / 2133 |
| Slots | 4 x DDR4 DIMM sockets |
| Max Capacity | Up to 128 GB (32 GB per DIMM) |
| Channel Architecture | Dual channel |
| ECC Support | ECC Un-buffered DIMM 1Rx8/2Rx8 modules (operate in non-ECC mode) |
| Non-ECC Support | Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 modules |
| XMP | Support for Extreme Memory Profile (XMP) memory modules |
| Note | CPU and memory configuration may affect supported memory types, speed, and number of modules (see GIGABYTE “Memory Support List” for details) |
BIOS
| Item | Details |
|---|---|
| ROM | 1 x 256 Mbit flash |
| Type | Licensed AMI UEFI BIOS |
| Standards | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
Graphics
| Item | Details |
|---|---|
| Integrated Graphics | Intel® HD Graphics support |
| HDMI Port | 1 x HDMI, max resolution 4096x2160 @ 60 Hz |
| HDMI Standard | HDMI 2.1, HDCP 2.3, native HDMI 2.1 TMDS compatible ports |
| DisplayPort | 1 x DisplayPort, max resolution 4096x2304 @ 60 Hz |
| DisplayPort Standard | DisplayPort 1.2, HDCP 2.3 |
Audio
| Item | Details |
|---|---|
| Codec | Realtek® Audio CODEC |
| Audio | High Definition Audio |
| Channels | 2/4/5.1/7.1-channel (configurable via audio software) |
| Digital Output | Support for S/PDIF Out |
| Note | 7.1-channel audio configurable in audio software; audio jack functions can be changed via software |
LAN
| Item | Details |
|---|---|
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless LAN
| Item | Details |
|---|---|
| WLAN | N/A |
Expansion Slots
| Source | Slot |
|---|---|
| CPU | 1 x PCI Express x16 slot, PCIe 5.0, running at x16 (PCIEX16)* |
| Chipset | 1 x PCI Express x16 slot, PCIe 3.0, running at x4 (PCIEX4) |
* PCIEX16 supports either a graphics card or an NVMe SSD. For a single graphics card, install it in the PCIEX16 slot.
Storage
| Source | Connector |
|---|---|
| CPU | 1 x M.2 connector (Socket 3, M key, type 2280, PCIe 4.0 x4/x2 SSD support) (M2A_CPU) |
| Chipset | 1 x M.2 connector (Socket 3, M key, type 22110/2280, PCIe 4.0 x4/x2 SSD support) (M2P_SB) |
| Chipset | 4 x SATA 6Gb/s connectors |
RAID
| Item | Details |
|---|---|
| SATA RAID | RAID 0, RAID 1, RAID 5, RAID 10 support |
USB
| Source | Ports |
|---|---|
| Chipset | 1 x USB Type-C® port with USB 3.2 Gen 2 support (via internal header) |
| 5 x USB 3.2 Gen 1 ports (3 x rear panel, 2 x internal header) | |
| 1 x USB 2.0/1.1 port (rear panel) | |
| Chipset + 2 USB Hubs | 8 x USB 2.0/1.1 ports (4 x rear panel, 4 x internal headers) |
Internal Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x CPU fan header
- 3 x system fan headers
- 3 x addressable LED strip headers
- 1 x RGB LED strip header
- 2 x M.2 Socket 3 connectors
- 4 x SATA 6Gb/s connectors
- 1 x front panel header
- 1 x front panel audio header
- 1 x S/PDIF Out header
- 1 x USB Type-C® header with USB 3.2 Gen 2 support
- 1 x USB 3.2 Gen 1 header
- 2 x USB 2.0/1.1 headers
- 2 x Thunderbolt™ add-in card connectors
- 1 x Trusted Platform Module header (for GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
- 1 x serial port header
- 1 x Q-Flash Plus button
- 1 x reset jumper
- 1 x Clear CMOS jumper
Rear Panel I/O
- 3 x USB 3.2 Gen 1 ports
- 5 x USB 2.0/1.1 ports
- 2 x antenna connectors (2T2R)
- 1 x HDMI port
- 1 x DisplayPort
- 1 x RJ-45 LAN port
- 3 x audio jacks
Form Factor
| Item | Details |
|---|---|
| Form Factor | Micro ATX |
| Dimensions | 24.4 cm x 24.4 cm |
Operating System Support
| OS | Support |
|---|---|
| Windows 11 64-bit | Supported |
| Windows 10 64-bit | Supported |
